1 PCS new SMC Flow Meter PF3A703H-N10-ES#LYQ007
1 PCS new SMC Flow Meter PF3A703H-N10-ES#LYQ007
1 PCS new SMC Flow Meter PF3A703H-N10-ES#LYQ007
Original Factory Precision Parameters (Model: SMC Flow Meter PF3A703H-N10-ES)
|
Parameter Category
|
Parameter Name
|
PF3A703H-N10-ES Specification
|
|
Basic Information
|
Product Model
|
PF3A703H-N10-ES; SMC Genuine Original Flow Meter, 100% unused and unrefurbished genuine parts; Thermal Mass Flow Meter, specialized for gas flow measurement in industrial automation systems, matching SMC pneumatic components and control systems.
|
|
Manufacturer Standard
|
Manufactured by SMC Corporation; Complies with CE, UL, ISO 9001, RoHS Standards; Conforms to SMC Internal Technical and Quality Norms for Flow Meters; Passes strict factory calibration and performance testing, meeting industrial precision measurement requirements.
|
|
|
Product Application
|
Gas Flow Measurement; Widely used in Pneumatic Equipment, Electronic Manufacturing, Precision Machinery, Automotive Parts Production, Semiconductor Industry and other scenarios, suitable for air, nitrogen and other inert gas flow monitoring and control.
|
|
|
Product Series
|
SMC PF3A Series Intelligent Flow Meter; Adopts advanced thermal mass flow measurement technology, integrated with digital display, signal output and parameter adjustment functions, realizing high-precision and intelligent flow measurement.
|
|
|
Core Measurement Parameters
|
Measurement Principle
|
Thermal Mass Flow Measurement; Uses constant temperature difference method, independent of pressure and temperature changes, ensuring accurate measurement under different working conditions, with high measurement stability.
|
|
Measured Medium
|
Air (Standard Condition), Nitrogen (N₂); Compatible with other dry inert gases (customizable); Not suitable for corrosive gases, humid gases or gases containing impurities.
|
|
|
Flow Measurement Range
|
Standard Air: 0.1 ~ 100 L/min (ANR); Nitrogen: 0.1 ~ 80 L/min (ANR); Wide measurement range, adapting to different flow requirements of industrial scenarios, with high precision in both low and high flow ranges.
|
|
|
Measurement Accuracy
|
±2% F.S. (Full Scale) for Flow Rate; ±1% F.S. (Repeatability); High measurement accuracy and good repeatability, ensuring reliable flow data collection for industrial control systems.
|
|
|
Response Time
|
≤ 100 ms (Fast Response Mode); ≤ 500 ms (Standard Mode); Fast response speed, real-time feedback of flow changes, ensuring timely adjustment of industrial control systems.
|
|
|
Measurement Unit
|
Switchable: L/min (ANR), m³/h (ANR), SCFM; Convenient for data reading and integration with different industrial control systems, adapting to different measurement unit requirements.
|
|
|
Zero Point Drift
|
≤ ±0.5% F.S./Year; Low zero point drift, reducing calibration frequency, ensuring long-term measurement accuracy and stability, lowering maintenance costs.
|
|
|
Temperature Coefficient
|
≤ ±0.05% F.S./℃ (0 ~ 50℃); Small temperature coefficient, reducing the impact of ambient temperature changes on measurement results, ensuring stable measurement accuracy.
|
|
|
Mechanical & Installation Parameters
|
Connection Type
|
NPT 1/8" Threaded Connection; Male Thread, Standard NPT Thread Specification, easy to install and disassemble, compatible with SMC standard pneumatic pipelines and fittings.
|
|
Pipe Diameter Compatibility
|
Suitable for Pipe Diameter: 6 ~ 10 mm; Compatible with standard industrial pneumatic pipelines, flexible adaptation to different pipeline layouts in industrial sites.
|
|
|
Dimensions (L×W×H)
|
85 × 55 × 38 mm (±0.1 mm); Compact structure, small installation space, easy to integrate with SMC pneumatic components and industrial control cabinets.
|
|
|
Structure Material
|
Housing: Engineering Plastics (Flame-Retardant ABS); Sensor Probe: Stainless Steel (SUS316L); High strength, corrosion-resistant, wear-resistant, suitable for industrial working environments.
|
|
|
Weight
|
≤ 80 g (Net Weight); Light weight, reducing pipeline load, convenient for installation and maintenance, suitable for mobile or light-load pipeline systems.
|
|
|
Installation Orientation
|
Horizontal / Vertical Installation (Horizontal Preferred); Installation Direction: Flow Direction Marked on Housing; Flexible installation, adapting to different pipeline layouts, ensuring measurement accuracy under correct installation.
|
|
|
Electrical & Signal Parameters
|
Power Supply
|
DC 24 V ±10%; Power Consumption: ≤ 1.5 W (Normal Operation); Stable power supply requirement, compatible with standard industrial DC power supplies, low power consumption, energy-saving and environment-friendly.
|
|
Signal Output
|
Analog Output: 4 ~ 20 mA DC (2-Wire/3-Wire Switchable); Digital Output: NPN Transistor (2 Channels, Optically Isolated); Supports flow alarm and flow switch control signals, convenient for integration into industrial control systems.
|
|
|
Analog Output Accuracy
|
±0.5% F.S.; High analog output accuracy, ensuring consistent signal transmission between the flow meter and the control system, improving control precision.
|
|
|
Digital Output Capacity
|
NPN Transistor: Max 100 mA/Channel (DC 24 V); Optically Isolated, strong anti-interference ability, ensuring stable signal output in complex electromagnetic environments.
|
|
|
Communication Function
|
Supports RS485 Communication (Modbus RTU Protocol); Baud Rate: 9600 ~ 115200 bps (Adjustable); Bidirectional data transmission, convenient for remote monitoring, parameter adjustment and data logging.
|
|
|
Display Function
|
4-Digit LCD Display (Backlight Optional); Real-time display of flow rate, cumulative flow and working status; Display brightness adjustable, convenient for reading in different lighting environments.
|
|
|
Protection Level
|
IP65 (Front Panel); Dustproof and Waterproof, suitable for industrial on-site environments, preventing dust and water splashing from damaging internal components, ensuring long-term stable operation.
|
|
|
Environmental & Protection Parameters
|
Operating Temperature
|
0 ~ 50℃ (Ambient Temperature); -10 ~ 60℃ (Fluid Temperature); Stable operation in a wide temperature range, adapting to different industrial working environments.
|
|
Storage Temperature
|
-20 ~ 70℃; Stable storage performance, no performance degradation after long-term storage in harsh environments, convenient for transportation and inventory.
|
|
|
Relative Humidity
|
10% ~ 90% (Non-Condensing); Resists humid industrial environments, no short circuit or malfunction caused by humidity, ensuring stable operation in coastal or wet areas.
|
|
|
Vibration Resistance
|
10 ~ 50 Hz, 0.35 mm Amplitude; Resists mechanical vibration generated by industrial equipment operation, ensuring stable measurement performance, no parameter drift or malfunction.
|
|
|
Shock Resistance
|
10 g (11 ms); Resists mechanical shock caused by equipment transportation or accidental collision, avoiding component damage, ensuring the integrity and reliability of the flow meter.
|
|
|
Service Life
|
≥ 50000 Operating Hours (Continuous Operation, Standard Working Conditions); High reliability, reducing maintenance frequency and cost of the flow measurement system, in line with SMC's high-quality product standards.
|
