1 PCS new ABB SC510 Interface Module #LYQ007
1 PCS new ABB SC510 Interface Module #LYQ007
1 PCS new ABB SC510 Interface Module #LYQ007
1. General Information (Original ABB Factory Standard)
|
Parameter
|
Specification
|
Unit
|
Notes (Original Factory Description)
|
|
Brand
|
ABB
|
-
|
Genuine ABB Original Factory Production, 100% Authentic, Industrial-Grade High-Reliability Symphony Plus Series Module[1][2]
|
|
Product Model
|
SC510 (Order Code: 3BSE003832R1)
|
-
|
Original ABB Factory Model, Factory Calibrated, No Modification, Belongs to ABB Symphony Plus Series Communication Interface Module[2]
|
|
Product Name
|
ABB SC510 Communication Interface Module
|
-
|
High-Precision Industrial Communication Interface Module, Specialized for ABB Symphony Plus Distributed Control System[2]
|
|
Product Type
|
Industrial-Grade Communication Interface Module, Symphony Plus Series
|
-
|
Acts as a gateway between different communication networks, supports real-time data exchange between controllers and SCADA[2]
|
|
Operating Voltage
|
24 VDC (Nominal); Allowable Range: 19 ~ 30 VDC
|
VDC
|
Original Factory Calibrated Voltage Rating, Compatible with Industrial Standard 24V Power Supply, Stable Operation[2]
|
|
Power Consumption
|
Approx. 5 W (Typical)
|
W
|
Low Power Consumption, Energy-Saving, Complies with ABB Factory Power Efficiency Standards[2]
|
|
Communication Interfaces
|
2×10/100 Mbps Ethernet (RJ45, TCP/IP); Optional RS232/RS485
|
-
|
Supports ABB’s S+ communication, seamless connection with Harmony/Melody controllers; galvanic isolation for communication ports[2]
|
|
Supported Protocols
|
IEC 60870-5-104, Modbus TCP, OPC UA (Depends on Firmware)
|
-
|
Optional RS232/RS485 supports Modbus RTU, DNP3 or proprietary protocols, high compatibility[2]
|
|
Redundancy Support
|
Hot Standby Redundancy (If Configured)
|
-
|
Supports hot standby redundancy configuration, ensuring continuous operation without data loss[2]
|
|
Cyclic Data Update Time
|
Typically < 100 ms (Depends on Configuration)
|
ms
|
Fast data update speed, ensuring real-time data exchange between controllers and upper-layer systems[2]
|
|
Operating Temperature Range
|
-20 ~ +70 °C (Ambient Temperature)
|
°C
|
Wide Temperature Adaptation, Stable Performance in Harsh Industrial Environments[2]
|
|
Storage Temperature Range
|
-40 ~ +85 °C; No Condensation
|
°C
|
Suitable for Long-Term Storage and Transportation in Extreme Temperature Conditions Without Performance Degradation[2]
|
|
Relative Humidity
|
5 ~ 95% RH (Non-Condensing)
|
% RH
|
Strong Humidity Resistance, Adaptable to High-Humidity Industrial On-Site Environments[2]
|
|
Protection Level
|
IP20 (Standard)
|
-
|
Dust-Tight Design, Suitable for Control Cabinet Installation, Prevents Dust Ingress and Damage[2]
|
|
Mounting Type
|
Standard 35 mm DIN Rail Mounting or Panel-Mounted
|
-
|
Flexible Mounting Options, Easy to Install and Disassemble, Convenient for On-Site Maintenance and Replacement[2]
|
|
Dimensions (W×H×D)
|
Approx. 100 × 120 × 75 mm (Tolerance: ±0.5 mm)
|
mm
|
Compact Design, Saves Control Cabinet Installation Space, Easy to Integrate with Other Symphony Plus Series Modules[2]
|
|
Weight
|
Approx. 0.35 kg (Including Housing and Connector)
|
kg
|
Lightweight Design, Reduces Load on DIN Rail or Panel, Convenient for Transportation and Installation[2]
|
|
Certifications
|
CE Certified, UL/CUL Certified, EMC Compliant (IEC 61000-6-2/4)
|
-
|
Complies with International Industrial Quality and Safety Standards, ATEX Certified (Depends on Variant), Applicable Globally[2]
|
|
Service Life
|
≥ 10 Years (Continuous Operation, Normal Working Condition); ≥ 50,000 Hours MTBF
|
Years, Hours
|
Long Service Life, Low Maintenance Frequency, Reduces Replacement Costs for Industrial Applications[2]
|
|
Warranty Period
|
12 Months (Original Factory Warranty)
|
Months
|
Complies with ABB Original Factory Warranty Standards, Covers Manufacturing Defects and Performance Issues[2]
|
|
Application
|
ABB Symphony Plus Distributed Control System, Power Plant Automation, Oil & Gas Control Systems, Water/Wastewater SCADA Integration
|
-
|
Widely Used in Various Industrial Automation Scenarios, Specialized for Real-Time Data Exchange and System Integration[2]
|
|
Compatible System
|
ABB Symphony Plus Control System, Harmony/Melody Controllers
|
-
|
Perfectly Compatible with ABB Symphony Plus Series, Plug-and-Play, Ensures Optimal System Performance and Stable Data Transmission[2]
|
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
