1PCS NEW ABB 3ADT315100R1001 SDCS-POW-4 #LYQ007
1PCS NEW ABB 3ADT315100R1001 SDCS-POW-4 #LYQ007
1PCS NEW ABB 3ADT315100R1001 SDCS-POW-4 #LYQ007
Part Number: 3ADT315100R1001 (Model: SDCS-POW-4)
Alternate P/N: N/A (Genuine ABB Component, Fully Compatible with ABB ACS Series Inverters)
Brand: ABB Industrial Automation
Product Category: Industrial Power Supply Board (Inverter Matching Power Module)
Product Series: ABB SDCS Series Power Modules (Dedicated for ABB ACS580/ACS510 Inverter Systems)
Core Application: Specifically designed as a dedicated power supply module for ABB ACS series inverters, widely applied in pump control, fan regulation, conveyor systems, and other industrial drive scenarios. It provides stable and reliable power conversion and supply for inverter control circuits and power units, ensuring continuous operation of inverters in harsh industrial environments such as food and beverage, textile, printing, rubber and plastic industries. Ideal for inverter systems requiring high protection level and anti-interference performance.
Core Features: High-efficiency AC-DC power conversion design; compatible with wide-range input voltage to adapt to different power grids; built-in comprehensive protection mechanisms for safe operation; rugged industrial-grade housing with strong EMI shielding performance; seamless integration with ABB inverter control systems; support for hot-swap maintenance to minimize downtime; low power consumption and low ripple output; built-in self-diagnostic function for real-time fault monitoring; compliance with international industrial safety and EMC standards; compact structure suitable for cabinet-mounted installation.
2. Electrical Specifications
Operating Voltage: 380V ~ 480V AC (three-phase), 50/60Hz (frequency adaptive); voltage tolerance: ±10%; output voltage: 24V DC (stable output), ripple voltage ≤1% Full Scale
Power Consumption: ≤35W (typical, full load operation); ≤40W (maximum, peak load condition)
Output Current: Rated Output Current: 5A DC; Maximum Output Current: 8A DC (short-term, 10 minutes); Overload Capacity: 120% of rated current for 1 minute, automatic protection after overload
Conversion Performance: Power Conversion Efficiency: ≥92% (full load condition); Response Time: ≤10ms (voltage fluctuation adaptation); Regulation Accuracy: ≤±0.5% Full Scale (output voltage)
Filtering Performance: Built-in high-performance EMI filter to reduce electromagnetic interference; low-pass filter for output voltage, configurable cutoff frequency; effectively suppress grid noise and ensure stable power supply for inverter control circuits.
Monitoring & Control Interface: Integrated signal feedback port for power status; compatible with ABB inverter internal communication bus; real-time transmission of power module working status, fault information to inverter control unit; support for remote monitoring via inverter system.
Protection Functions: ESD Protection: ±8kV (contact discharge), ±15kV (air discharge) per IEC 61000-4-2; Overvoltage/Undervoltage Protection (input/output); Overcurrent Protection; Short-Circuit Protection (output side); Overheating Protection with automatic shutdown and alarm; Isolation Protection: 2500V AC (power circuit to control circuit, 1 minute); Reverse Polarity Protection (power input).
