1 PCS NEW Di-Soric LHT 9-45 M10 P3IU-B4
1 PCS NEW Di-Soric LHT 9-45 M10 P3IU-B4
1 PCS NEW Di-Soric LHT 9-45 M10 P3IU-B4
- Emission light: red laser, wavelength 650nm, modulated.
- Laser grade: 2 (IEC60825-1).
- Operating voltage: 18-30VDC
- Internal power consumption: <150 mA.
- Spot diameter: about 6mm.
- Detection range: 200-10000mm.
- Switch output: pnp, 200mA, NO/NC, switchable.
- Analog output: 0-10V 4-20mA, linearized.
- Working frequency: 5Hz.
- Output sequence frequency: 1-33Hz.
- Ambient temperature: -10-60℃.
- Load resistance :0-10V.
- Ambient light immunity: 100 kLx.
- Protection grade: IP67.
- Protection grade: Ⅲ, working under protective low voltage.
